Robotics & IoT Case Study
IgnisGuard 1 IgnisGuard 2

IgnisGuard | Autonomous Fire Extinguishing System ๐Ÿ”ฅ

An intelligent hardware solution designed to detect fire outbreaks in real-time and take immediate action to suppress them.

  • Real-time Detection: High-sensitivity flame sensors detect hazards instantly.
  • Self-Acting Sprinkler: Automatically triggers water pump to extinguish flames.
MicrocontrollerArduino Uno
SensorsIR Flame & Smoke
Robotics & IoT Case Study
Smoke Alert 1 Smoke Alert 2

Mini IoT Smoke & Gas Alert System ๐Ÿ’จ

Advanced monitoring system designed to detect harmful gas leakages and smoke density in real-time for industrial safety.

  • Gas Detection: Identifies LPG and combustible gas leakages instantly.
  • Emergency Alarm: Triggers the active buzzer immediately upon detection.
MicrocontrollerArduino Uno
SensorsMQ-2 Smoke & Gas
Robotics & Defense Case Study
IADS 1 IADS 2

Intelligent Air Defense System (IADS) ๐Ÿ›ฐ๏ธ

An advanced radar-based tracking system that detects unauthorized aerial targets and provides real-time visual monitoring using Processing.

  • Target Tracking: Real-time 180ยฐ sweep with Ultrasonic precision and servo synchronization.
  • Multi-Level Alert: Traffic Light LEDs and high-decibel Buzzer for proximity warnings.
  • Radar UI: Interactive Processing interface to visualize target distance and angle.
MicrocontrollerArduino Uno R3
Radar SensorHC-SR04 Ultrasonic
ActuatorServo SG90
Display16x2 I2C LCD
IoT & Home Automation
Smart Home 1 Smart Home 2

DIY Smart Home Automation ๐Ÿ“ฑ๐Ÿ’ก

A complete IoT solution to control home appliances like lights and fans wirelessly using a smartphone and Arduino.

  • Wireless Control: Manage appliances from anywhere using a custom mobile interface.
  • Relay Integration: Safely switching AC appliances through low-voltage DC signals.
  • Energy Efficient: Smart scheduling and remote cut-off to reduce power consumption.
ControllerArduino & BT/WiFi Module
Switching4-Channel Relay Module
PlatformCustom Android App
Power5V DC Adapter
Smart Home & Automation
Rain Safe 1 Rain Safe 2

Smart Rain Safe Clothes System ๐ŸŒง๏ธ๐Ÿ‘—

An automated system that detects rain via sensors and triggers a servo motor to pull laundry into a sheltered area instantly.

  • Rain Detection: High-precision rain sensor identifies water droplets immediately.
  • Auto Protection: Servo motor mechanism moves the clothesline to a safe zone.
  • Audio Alert: Integrated buzzer notification when rain starts.
MicrocontrollerArduino Uno
SensorRain Sensor Module
ActuatorServo Motor
AlertPiezo Buzzer
Smart Security & Robotics
Security 1 Security 2

Smart Proximity Security System ๐Ÿš€๐Ÿ”

A reactive security solution that monitors distances and triggers multi-level alerts when unauthorized entry is detected.

  • Smart Detection: Ultrasonic/Proximity sensors measure real-time distance.
  • Security Alert: Automated LED indicators and high-decibel buzzer alarms.
  • Monitoring: Real-time feedback via Serial Monitor or Display.
Main BoardArduino Uno
SensorUltrasonic / Proximity
AlertBuzzer & LED Lights
LogicDynamic Thresholds
Agriculture Tech & IoT
Irrigation 1 Irrigation 2

Smart Plant Irrigation System ๐Ÿชด๐Ÿ’ฆ

An automated gardening solution that monitors soil moisture in real-time and controls water pumps using relay logic.

  • Auto Watering: Automatically triggers pump when soil moisture falls below threshold.
  • Status Monitoring: Traffic Light LEDs indicate Dry (Red), Optimal (Green), or Transition (Yellow).
  • Relay Control: Safely handles 5V water pumps through high-current relay switching.
ControllerArduino Uno / Nano
Soil SensorCapacitive/Resistive
IndicatorsTraffic Light Module
Actuator5V Relay & Pump
Home Automation & UX
Clap Light 1 Clap Light 2

Smart Clap-to-Light Interface ๐Ÿ‘๐Ÿ’ก

A professional acoustic-controlled system that toggles multiple lighting modes based on the number of handclaps.

  • Acoustic Logic: Sophisticated clap-counting algorithm to prevent false triggers.
  • Multi-Mode: 1 Clap (Red), 2 Claps (Yellow Off), 3 Claps (Green Mode Toggle).
  • Visual Feedback: 16x2 I2C LCD displays real-time clap count and system status.
ProcessingArduino Uno
Audio SensorLM393 Sound Sensor
Display16x2 I2C LCD
InterfaceTraffic Light/Relay
Safety & Security
Quake-Guard 1 Quake-Guard 2

Quake-Guard: Earthquake Detector โš ๏ธ

An Arduino-based seismic monitoring system that detects ground vibrations and triggers real-time visual and auditory alerts.

  • Vibration Detection: Uses high-sensitivity vibration sensors to monitor seismic activity.
  • Instant Alert: Triggers buzzer and LEDs immediately when threshold is crossed.
  • Live Status: Real-time monitoring showing "SAFE" or "ALERT" based on movement.
ControllerArduino Uno
SensorVibration Sensor
AlertBuzzer & LEDs
LogicThreshold Trigger
Health & Hygiene
Sanitizer 1 Sanitizer 2

Touchless Sanitizer Dispenser ๐Ÿงดโœจ

A completely touch-free hygiene system that automatically dispenses liquid using IR proximity detection.

  • Touch-Free: IR sensor detects hands without any physical contact for maximum safety.
  • Auto Dispense: Arduino activates a mini pump via relay to dispense the liquid.
  • Smart Logic: Precisely controlled dispensing time to prevent liquid wastage.
ControllerArduino Uno
SensorIR Proximity
ActuatorRelay & Mini Pump
Power5V-12V DC
